Efficiency Brushless Pelton Turbine Generator 100kw-50mw Power Output IP54 Protection Grade

Efficiency Brushless Pelton Turbine Generator 100kw-50mw Power Output IP54 Protection Grade

100kw Pelton Turbine Generator

IP54 Pelton Turbine Generator

50mw Pelton Turbine Generator

Place of Origin:


Brand Name:




Model Number:

CJ-pelton hydro turbine

Contact Us

Request A Quote
Product Details
Protection Grade:
Cooling Method:
Air/Oil Cooling
Insulation Class:
Power Output:
Excitation Mode:
Brushless Or Thyristor
Power Plant/Hydropower Station
Payment & Shipping Terms
Minimum Order Quantity
1 set
Packaging Details
Export packing (wooden cases+plastic film )
Delivery Time
150 Days
Payment Terms
Supply Ability
500 per year
Product Description

Efficiency Brushless Pelton Turbine Generator 100kw-50mw Power Output IP54 Protection Grade

Product Description:

Our Pelton Turbine Generator operates within a speed range of 500-3000r/min, making it a versatile generator for various hydroelectric power plants. It is capable of generating a rated current of 100-1000A, making it a reliable source of power for your facility.

The Pelton Turbine Generator is designed with cooling in mind. It comes with the option of either air or oil cooling. This allows for efficient cooling, ensuring that the generator operates at optimal temperatures, while prolonging its lifespan.

Our Impulse Turbine Generator is perfect for power plants and hydropower stations looking for an efficient and reliable source of power. It is designed to withstand the rigors of continuous operation, making it a long-term investment for your facility.



  • Product Name: Pelton Turbine Generator
  • Efficiency: 85-95%
  • Excitation Mode: Brushless Or Thyristor
  • Cooling Method: Air/Oil Cooling
  • Material: Cast Iron/Stainless Steel
  • Rated Current: 100-1000A
Efficiency Brushless Pelton Turbine Generator 100kw-50mw Power Output IP54 Protection Grade 0Efficiency Brushless Pelton Turbine Generator 100kw-50mw Power Output IP54 Protection Grade 1

Technical Parameters:

Pelton Type Turbine Generator Pelton Turbine Generator
Speed Range 500-3000r/min
Power Output 100kw-50mw
Dimension Customized
Application Power Plant/Hydropower Station
Cooling Method Air/Oil Cooling
Insulation Class F
Excitation Mode Brushless Or Thyristor
Protection Grade IP54
Rated Voltage 6-10kV
Weight 5-50t
High Head Pelton Turbine


DSSD CJ-pelton hydro turbine is a Pelton Turbine Power Generator with high efficiency ranging from 85% to 95%. This Pelton Type Turbine Generator can produce power output of 100kw to 50mw, making it suitable for small and large hydropower projects. The product is made in DeYang, SiChuan, China and is certified with ISO, CE, and TUV standards, ensuring the quality and safety of the product.

The Pelton Turbine Generator is ideal for various occasions and scenarios. For instance, it can be used in remote areas where there is no access to the grid. The generator can harness the power of water to generate electricity, which can be used to power homes and businesses. Additionally, the Pelton Turbine Generator can be used in areas prone to power outages. It can serve as a backup power source and ensure that critical infrastructure, such as hospitals and emergency services, remain operational.

The Pelton Turbine Generator is also suitable for use in industrial applications. It can be used to power manufacturing plants and other heavy industries that require a continuous supply of electricity. The generator is highly efficient and can help reduce energy costs and improve the overall productivity of the plant. Moreover, the Pelton Turbine Generator can be used in large-scale hydropower projects. Its high power output and efficiency make it an ideal choice for generating clean energy on a large scale.

The DSSD CJ-pelton hydro turbine comes in a range of weights from 5t to 50t, and has a rated voltage of 6-10kV. The product is packed and shipped using export packing (wooden cases+plastic film), ensuring that it arrives at its destination safely. The Pelton Turbine Generator has a minimum order quantity of 1 set and a price of 30000 USD. The delivery time is approximately 150 days, and the payment terms are EXW. The product has a supply ability of 500 units per year, making it readily available for customers who need it.




Support and Services:

The Pelton Turbine Generator is a high-performance hydro power generator that is designed to efficiently convert the power of water into electricity. It is built to withstand tough operating conditions and is ideal for use in rugged environments. Our product technical support and services include:

  • On-site installation and commissioning
  • Regular maintenance and repair services
  • 24/7 technical support
  • Performance optimization services
  • Training and education for operators and maintenance personnel

Our team of experienced technicians and engineers are dedicated to providing you with the highest quality support and services to ensure the optimal performance of your Pelton Turbine Generator.
