customized product Turgo Turbine for hydropower station
Turgo turbine
Conventional hydropower stations use the energy producted by flowing water. People use mechanicas to convert energy into electricity.
Hydro turbine uses water as fuel source, hdyroelectricity is cheap. What's more, it is environmentally friendly to the environment.
Turgo turbine is one of the hydro turbine that welcomed by people.
It is used to the power station with low water head and large water flow. The specific speed range of the Turgo turbine is between the Pelton and Francis turbines. This parameter is between 8.5 and 30 for a single-jet Pelton; while Francis specific speed range is between 50 and 400. You can see them in the middle and mini hydropower station.
Advantages:
(1) the machine are powerful, noiselessly, good stability, failure free operation, high quality and deeply trusted by home and abroad customers.
(2) Covers the boundary between Francis and Pelton
(3) Limits over-Pressure effect over the penstock
(4) Ease of operation and maintenance
Parameters of Turgo Turbine
| Water Head | 25m~300m |
| Runner diameters | 0.45m~5m |
| Power Range | 50kw~20mw |
| Frequency | 50HZ/60HZ |
| Generator Voltage | 400v, 800v, 6300v, 10500v |
| Layout pattern | Horizional or Vertical |
| Material | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless or Static excitation system |
| Generator Insulation | F/F |
| Life span | 30~50years |
| Color | Customized |
About our company:
Deyang Dongsen Hydropower Equipment Co.,Ltd is a professional comprehensive technology engineering company in design, manufacturing, installation and maintenance of hydropower equipment as well as in the hydropower station investment.
Our team:
There are more than 20 workers ,5 professional technical R&D personnel,5 sales representative in our factory,
We have:
5 types of water turbine generator: Francis turbine, Pelton turbine, Turgo turbine, tubular turbine and kaplan turbine.
Package & Delivery
For each order we will adopt different packaging methods for each part of the product.
1. In order to prevent damage to the products, plastic film wrapped the important parts of water turbine, water turbine generator, shaft etc. are usually packaged in cartons.
2. Free consultation service before, during, and after sales.
3.We provide 1 year complete warranty service.
We offer:
1. Professional advice for client.
2. provide installation guidance.
Why choose us?
1.Rich experience---served for more than 500 HPPs
2. Long life span: 30~50 years
3. Top-class design--from DEC
4. Quality guarantee---AAA
5. Delivery guarantee--flexible and high efficiency
6. Lower cost---lower management and labor cost
7. convenient---from penstock to commissioning
