10 Ton Double Beam Crane For Flat Range Material Transportation

10 Ton Double Beam Crane For Flat Range Material Transportation

10T Double Beam Crane

A5 Double Beam Crane

a6 double beam overhead crane

Place of Origin:

china

Brand Name:

DSSD

Model Number:

double beam crane good price

Contact Us

Request A Quote
Product Details
Certification:
CE,iso
Condition:
New
Warranty:
2 Years
Span:
Comtomized
Feature:
Bridge Crane
After-sales Service Provided:
Field Maintenance And Repair Service
Rated Lifting Moment:
50KN-4800KN
Product Name:
Nucleon Overhead Mobile Bridge Crane 30t16t 100t 1000t,02 Discount Bridge Crane 20/5t Double Girder Bridge Overhead Crane
Application:
Factory. Widly Used
Type:
Double Girder Overhead Traveling Bridge Cranes,LDA Single Girder Overhead Crane,Hoist Single Girder Bridge Crane
Crane Feature:
Double Girder Overhead Bridge Crane Price
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiation
Packaging Details
Wooden packing
Delivery Time
3 months
Payment Terms
D/P, D/A, L/C, T/T
Supply Ability
1000SET
Product Description

High Efficiency Chinese Supplier Double Beam Crane best Price



Product Paramenters


The double-beam crane is composed of a straight rail, a crane main beam, a hoisting trolley, a power transmission system and an electrical control system. It is particularly suitable for large suspension and large-lifting flat range material transportation. The double girder bridge crane has strong carrying capacity, large span, good overall stability, and many varieties. However, its quality is larger than that of a single girder gantry crane with the same lifting weight, and the cost is also higher. According to the different main beam structure, it can be divided into box beam and truss. Generally, a box-shaped structure is used. The main products are: double girder crane, double girder bridge crane, electric double girder bridge crane, electric double girder crane, double girder crane, European double girder crane, bridge double girder crane

Double Beam Crane PRODUCT SPECIFICATIONS
lifting capacity(TON)

10
16/3.2
20/5
25/5
32/5
50/10
Span(M)
10.5-31.5
Lifting height(M)
Main hook
16
16
12
12
16
12
Auxiliary hook

18
13
13
18
16
Crab speed(m/min)

43.8
44.6
44.6
37
42.4
38.5
Travelling speed(m/min)
A5
89.8/91.9
84.7/87.6
84.7/87.6
85.5/88
74.2/87.6
74.6
A6
112.5/116.8
112.5
112.5/101.4
112.5/101.4
8608/101.4
87.3
Total weight(KG)
A5
14270
19128
19947
20795
26901
35317
A6
14719
20045
20984
22632
28061
36075
Maximum wheel load(KN)
A5
102-160
141-205
163-231
185-255
237-327
333-450
A6
104-162
145-211
167-239
189-263
242-355
336-457
Track recommendation
Trolley
15kg/m
43kg/m
crane
38kg/m
43kg/m
Energy source
According to customer demand
