0.25 Inch Shell Heat Exchanging System with Dia 1/2 Inch Tube and 20 Feet Tube Length

Product Description:

Heat Exchanger is a type of thermal exchanger device used in industrial applications for transferring thermal energy from one medium to another. It utilizes a combination of tubes and shell to accomplish the heat exchanging process. The tube length of the heat exchanger is 20 feet, which allows for a flow rate of 10 Gallons Per Minute (GPM) to pass through the system. The diameter of the tubes is 1/2 inch, while the diameter of the shell is 4 inches and its length is 6 feet. This heat exchanging system is designed to provide a high level of efficiency and durability for a wide range of industrial applications.

The Heat Exchanger is a reliable and cost-effective way to transfer thermal energy from one source to another. It is widely used in many industries, including power generation, food processing, and chemical production. This system is designed to be robust and reliable, with a long-lasting life expectancy. The thermal efficiency of the thermal exchanger is maximized by utilizing advanced materials and engineering designs, which increase its performance and reliability. The Heat Exchanger is an optimal choice for companies looking for a reliable and efficient thermal exchanger.

Features:

• Product Name: Heat Exchanger
• Shell Thickness: 0.25 Inch
• Design Code: ASME Section VIII, Div. 1
• Shell Diameter: 4 Inch
• Type: Shell And Tube
• Manufacturer: ABC Company
• Heat Exchange Machine
• Thermal Exchanger
• Heat Transfer Equipment

Technical Parameters:

Applications:

Heat exchangers, such as the DSSD model, are an important part of many industrial applications. They are used to transfer thermal energy between two fluids without the two fluids mixing. This type of heat exchange machine is highly efficient, and the DSSD model is capable of operating at a temperature rating of 400°F and a shell diameter of 4 inches. The heat exchanger consists of a shell and tube design, with a shell thickness of 0.25 inch and two passes. In addition, the DSSD heat transfer device is equipped with ISO, CE, and TUV certifications, and is available for purchase with a minimum order quantity of one set. The price of the heat exchange machine is 3000, and the delivery time is 60 days. The packaging details are export packing (wooden cases + plastic film). DSSD also provides a supply ability of 500 per year, and payment terms are EXW.

Customization:

Heat Transfer Equipment, Heat Exchange Machine, Heat Transfer Equipment, Heat Exchanger

Brand Name: DSSD
Model Number: Customized
Place of Origin: China
Certification: ISO,CE,TUV
Minimum Order Quantity: 1 set
Price: 3000
Packaging Details: Export packing (wooden cases+plastic film)
Delivery Time: 60 Days
Payment Terms: EXW
Supply Ability: 500 per year
Number of Passes: 2
Tube Diameter: 1/2 Inch
Nozzles: 2
Tube Length: 20 Feet
Type: Shell And Tube

Packing and Shipping:

Packaging and Shipping for Heat Exchanger:

• The Heat Exchanger will be securely packaged in a cardboard box.
• The box will be filled with foam to ensure the Heat Exchanger does not move or break during transit.
• The Heat Exchanger will be shipped via a reliable and trusted carrier.
• The Heat Exchanger will be shipped with tracking and insurance to ensure it arrives in perfect condition.
